Standards —
IEC 332, 754, 1034, 811 & HD 624.7, TIA/EIA 568-b.2-1 CAT6 CPR Euroclass level Dca-s2,d2,a1 Conductor — Material: Solid Bare Copper; Size: 23AWG x 4P; Construction: 1/0.560±0.02 mm Insulation — Material: HDPE; Average Thickness: AVG. 0.220 mm; Minimum Thickness: AVG. 0.210 mm; Diameter: 1.00±0.02 mm; Colour: 1. White/Blue Stripe & Blue; 2. White/Orange Stripe & Orange; 3. White/Green Stripe & Green; 4. White/Brown Stripe & Brown Shielded — Pair Stranded: 2 Cores Stranded; Filler (Slot): PE Isolator Separator; Assembly Stranded: 4-Pair Stranded Jacket — Average Thickness: 0.45 mm; Minimum Thickness: AVG. 0.40 mm Diameter: 6.10±0.20 mm Material: LSZH Rating/Temperature Voltage — 75°C, 300V Conductor Resistance — 93.8 Ohm/km@20°C Max. Mutual Capacitance — 56 pFm Max. Dielectric Strength — AC 1.5 Kv/2Sec Min. Spark Test — 2.5 KV Insulation — Unaged Tensile Strength: 2400 PSI Min. (1.69 kg/m m²); Unaged Elongation: 300% Min.; Aged Tensile Strength: Unaged Min. 75% (100°C x 48Hrs); Aged Elongation: Unaged Min. 75% (100°C x 48Hrs); Jacket — Unaged Tensile Strength: 1306 PSI Min. (0.92 kg/m m²); Unaged Elongation: 125% Min. Aged Tensile Strength: Unaged Min. 70% (100°C x 168Hrs); Aged Elongation: Unaged Min. 70% (100°C x 168Hrs); Insulation Shrinkback — 150m/m, 121°C±1°C x 1Hr <9.5m/m Cold Bend Test — -20°C x 4Hrs No. Crack. Flame Retardant Test — IEC 60332-1 Acid Gas Evolution — PH>4.3. Smoke Generation — 60% Min. (Transmission of light) DC Resistance Unbalance — 5% Max. Pair-to-ground capacitance balance — 3300 pFm/km Max. Characteristic impedance — 1-400MHz 100±15 Ohms Structural Return Loss — 400MHz 8.6dB Min Propagation Delay — 400Mhz 536nS/100m Max. Delay Skew — 1-400MHz 30nS/100m Max. |
